6.0 mm2
6.0 mm2
Regular price
Rs.23,500.00 PKR
Regular price
Rs.26,500.00 PKR
Sale price
Rs.23,500.00 PKR
Unit price
/
per
Couldn't load pickup availability
Application: Especially for the connection between Solar power generation device connector and connection of inverter, Under the condition of different climate outdoor installation, and can adapt to the dry and wet indoor working environment. It is a single insulated wire.
| Weight | 76 Kg |
|---|---|
| Select Color |
White ,black ,Green, blue, red |
| Length |
90 meters |
| No. of Strands | 7 |
| Strand Diameter |
.64 Inch or 1.62 mm |
| Conductor Type |
Copper |
| Insulation Type |
Poly Vinyl Chloride (PVC) |
| Standard |
Yes |
| Temperature Rating |
-20C˚ to 70C˚ |
| Dc Resistance |
1.24M Ohm/Km |
| Insulation Resistance |
0.0052M Ohm/Km |
| Voltage Rating |
300/500V |
| Ampere Rating |
31 Amps |
